ER series Full Automatic Production Line Current Location:Home > Products > Full automatic production line > ER series Full Automatic Production Line
ModelER3710 Full Automatic Production Line for Pulse Transformer
Model:   Browse:1199

Mechanical properties:
1.  Automatic loading 、sorting and testing, loading and unloading winding on the belt conveyer,soldering.
2. The body of machine is made of high quality resin sand senior castings.
3. The machine base uses the steel plate seamless welded,which can strengthen the bearing,reduce noise and vibration,and improve the stability of the machine.
4. Use imported guide ways and ball screw in order to ensure the accuracy of positioning and repositioning.
5. The assembly of high speed main spindle is through the strict quality control,which ensures high speed,low noise and long service life.
6. Use appropriate procedures and replace the jig to change models.
7. The bobbin check sensor can check the bobbins that arent inserted in place. The machine timely alarms and shuts down,which can effectively avoid the breakage of the guiding needle.
8. Application to big scale orders for long term.



Main configuration:
1. Panasonic servo motor and imported guide ways and ball screw
2. Japan’s SMC cylinder and koganei pneumatic electromagnetic valve
3. Japan’s Keyence optical fiber sensor,Omron photoelectric switch and SMC magnetic switch
4. Japan NSK high speed bearings and Samsung belt



Main characters:
1. The running speed and position speed is quickly and precisely,Terminal wrapping angle selectable,vertical or horizontal.
2. Winding species may be based on customer expectation value design
3. Convenient terminal wire disposal: a: snap or cut by scissors; b: fallen into scrap box
4. Program mode: using touch screen to program,provide man-machine interface teaching system to edit program.
